Indoor LED Interactive Floor Screen
The floor screen needs to be waterproofed regardless of whether it is indoors or outdoors. Our company's indoor modules completely adopt outdoor standards. The screw holes are sealed with three-proof glue to ensure moisture-proof, waterproof and dust-proof to the greatest extent. The waterproof and dustproof coefficient of the surface can reach IP54 for the indoor model. and the front and back of the outdoor model have IP68 protection level. The number of load-bearing columns in each module is as many as 71, and adhesives are added to the material to ensure the toughness and strength of the load-bearing columns, not only can it guarantee the weight of 2600KGS/SQM, but it can also ensure that the tension generated when the heavy object goes up and down ensures that the column does not break (the tension will cause the column to break, and after the break, the module will crack when the weight is removed and put on it again) .
In order to ensure the load-bearing requirements, the panel is made of sheet metal with a national standard foot of 1.50mm and a thickness of 1.80mm after spraying. The force is distributed evenly on the whole box, not on several points. The back cover of the control box is made of pure aluminum, which ensures heat dissipation to the greatest extent. Waterproof beading is used around the back cover to ensure that water vapor on the ground cannot enter the control box. The floor support is made of galvanized floor support instead of hard plastic, which increases the load-bearing effect.
20+ YEARS
Industry Experience
3000 KGS/㎡
Load Bearing
2 YEARS
Warranty
100+
Country
200+
City
1000+
Project
ISO9001, CE, RoHS, FCC, CCC, UL, EMC.
Private model customized modules and cabinets.
Screen heights can be customized.
PC housing, anti-slip, anti-glare, wear-resistant, UV resistance.
Maximum load capacity of 3000 KGS/m^2.
Customized maintenance tool.
Cabinet material can be selected.
Lifespan over 100000 hours, 2 years warranty.
Complete test reports and certificates.
Multi-equipment linkage, better audiovisual effect.
|
Model |
P2.5 |
|
|
Module Specification |
Pixel composition | SMD LED 1R, 1G, 1B |
| Pixel pitch（mm） | 2.5（W）×2.5（H） | |
| Module resolution（W×H） | 100×100 | |
| Module size（mm） | 250（W）×250（H）×16（D） | |
| Module weight（kg） | 2.1 | |
|
Steel Cabinet Specification
|
Unit cabinet size（mm） | 500(W)*500(H)*78(D） |
| Cabinet weight （kg/㎡） | 44 kg（500(W)×500(H)×78(D） | |
| Floor support weight （kg/piece) | 2kg | |
| Weight（kg/Outer packing wooden box plus box body） | 8pcs/wooden carton，192kg | |
| Outer packing wooden carton dimension（L x H x D ) | 8pcs/wooden carton：1070*680*570mm（L*W*H） | |
| Pixel density（dot/㎡） | 160000 | |
| Protection level | Indoor（front IP65，back IP43） | |
| Cabinet flatness（mm） | ≤1 | |
| White balance brightness（nits） | Indoor≥1300（CCT 9500K） | |
| Color temperature（K） | 3200—9300Adjustable | |
| Horizontal perspective（ °） | >120 | |
| Center distance deviation of luminous point | <3% | |
| Brightness uniformity | ≥97% | |
| Chromaticity uniformity | Within ±0.003Cx,Cy | |
| Max contrast | 6000:1 | |
|
Electrical parameters |
Power consumption (A/unit module) | DC 6∽7 |
| Peak power consumption（W/cabinet；W/㎡） | 400 ；800 | |
| Average power consumption（W/cabinet；W/㎡） | 200；400 | |
| Power requirements | AC220V（50-60Hz） | |
|
Processing performance |
Pixel sharing technology | Yes |
| Drive way | Constant current drive | |
| Frame change frequency（Hz） | 50&60 | |
| Refresh rate（Hz）@60HzFrame rate signal source | ≥1920/≥3840/7680 | |
|
Ambient specification
|
Lifespan | 100000 hours |
| Work temperature | -20 — 55℃ | |
| Storage temperature | -30 — 60℃ | |
| Humidity （RH）no condensation | 10 - 90% | |
| Storage temperature（RH）no condensation | 10 - 95% | |
| Screen thickness | module+cabinet：78mm，screen+floor support：150∽170mm adjustable | |
| Defective ratio | ≤4/100000 | |
| Unit module splicing gap | Uniformity and ≤2mm | |
| Best view distance | 3-15m | |
| View angle | horizontal>120° | |
| Surface flatness | Max tolerance≤1mm | |
| Screen surface color | Uniformity 95%（white transparent or tea color） | |
| Brightness Uniformity | 95% | |
| Brightness | ≥1300CD/㎡ | |
| Circuit layout | Light-driven integrated SMD technology, evenly distributed light-emitting pixels, suspended circuit board design, no stress, reasonable layout, standard and beautiful wiring, stable and reliable | |
| Loading bearing capacity | 1.5 tons /㎡；1545/N（single point ） | |
| Friction coefficient | Static friction coefficient 0.79/Us | |
| Dynamic friction coefficient 0.71/UD | ||
| Certifications | CE、FCC、 ROHS、 CCC 、Certification of load-bearing, waterproof, heating, friction coefficient, etc. | |
|
Control system requirement |
||
|
Control computer
|
OS | Windows 7 64bit、Windows 10 64bit、Windows 10 64bit. |
| CPU | Intel core i7 6200U | |
| CPU main frequency | 2.3GHz | |
| Highest Turbo Frequency | 2800MHz | |
| Number of cores/threads | Dual cores/quad threads | |
| Level 3 cache | 3MB | |
| Memory Capacity | 4GB | |
| Memory type | DDR3L(low voltage)1600MHz | |
| Slots number | 2Xso-DIMM | |
| Max memory capacity | 16GB | |
| Hard-disk description | 5400r | |
| Display resolution | Over 1366*768 | |
| Display photographic card | Performance-level discrete graphics | |
| Cache capacity | 2GB | |
| Lan network card | 1000Mbps Ethernet card | |
| Data interface | 3Xusb3.0 | |
| Video interface | VGA、HDMI | |
